A Next-Generation Handheld Terminal
for Cutting-Edge Scanning Performance
PM452

The PM452 is a rugged handheld terminal packed with cutting-edge features,
including a powerful processor and advanced scanning engine. With superior durability,
it delivers top-tier performance in any enterprise environment.

PM452
PM452
PM452
PM452
PM452
1
/
1
PM452

  • Wi-Fi 6E

  • 2.2 GHz Octa-core

  • 4.3” Gorilla Glass

  • 2.0 m (6.6 ft.) drop

  • IP65

  • 1,000 cycles tumble

PM452
PM452
A Precisely Tuned Device for Optimal Scanning Performance

The 2.2 GHz processor, 6 GB RAM / 128 GB flash storage ensure exceptional data processing speed, effectively decoding barcodes even in challenging conditions such as low-light environments or damaged barcodes. The 13 MP high-resolution camera on the top of the device utilizes PDAF (Phase Detection Autofocus) technology to capture sharp images instantly.

PM452
PM452
  • Enhanced Network
    Performance for
    Seamless Workflow
  • Wi-Fi 6E technology

    The PM452 is equipped with Wi-Fi 6E technology,
    offering outstanding network performance and efficiency.

  • Enabling efficient handling
    of large volumes of data

    Wi-Fi 6E enhances data security, reduces battery consumption,
    and significantly improves data transmission speeds,
    enabling efficient handling of large volumes of data.

Powerful Battery Performance for Uninterrupted Operations

The 5,700 mAh high-capacity battery ensures continuous operation, even during long working hours. A 60 mAh backup battery supports the Hot Swap, allowing battery replacement without powering off the device, ensuring uninterrupted workflow.

PM452
PM452
PM452
PM452
Various Options to Meet Specific Business Needs

The PM452 offers three scanning engine options, including a standard-range 1D/2D scanner and a long-range scanner capable of reading barcodes from up to 29 m (95.1 ft) away. Additionally, customers can customize their devices with three different keypad options: numeric, alphanumeric, and function-numeric, tailored to specific business needs.

PM452
  • Unmatched Durability
    for Any Business Environment
  • Rain/dust proof

    It features an IP65-rated dustproof and
    waterproof design, with a wide operating temperature range
    of -20 °C to 60 °C (-4 °F to 140 °F).

  • Drop

    Designed to withstand multiple drops
    from 2.0 m (6.6 ft) onto a concrete surface.

  • Tumble

    Successfully tested to withstand 1,000 tumbles
    from a height of 1.0 m (3.3 ft), ensuring durability
    against repeated impacts.

Specifications
Dimensions
(L x W x D) 		214.9 x 77.3 x 39.3 mm
8.5 x 3.0 x 1.6 in.
Weight 450 g
15.9 oz.
Power Standard battery: 4,000 mAh, 3.7 V, Li-ion rechargeable
Extended battery: 5,700 mAh, 3.63 V, Li-ion rechargeable
Back-up battery: 60 mAh, 3.7 V (10C), Hot-Swap
Display 4.3”, IPS panel (480 x 800 pixels), WVGA
LED backlight
Daylight readable (max. 500+ nits)
Wide viewing angle
Multi-touch capacitive
Corning Gorilla glass
OS Android 13 (upgradeable to Android 18)
Processor Octa-core @2.2 GHz
Memory and storage 4 GB / 64 GB or 6 GB / 128 GB
Communication WWAN: LTE
WLAN: IEEE 802.11 a/b/g/n/ac/ax/d/h/i/k/r/v, Wi-Fi 6E, Wi-Fi Direct and Hot Spot support, 1x1 MU-MIMO
WPAN: Bluetooth Class I, ver. 5.2, BLE support
Data capture Scan engine: Three 1D/2D scan engine options including flexible range and extra-long range
Camera: 13 MP, F. No. 2.0, PDAF (Phase Detection Auto Focus), LED flash
Drop 2.0 m (6.6 ft.) multiple drops to concrete surface at room temperature
1.8 m (6 ft.) across the operating temperature range, MIL-STD-810H
Rain/dust Proof IP65
Downloads
